ATSC 3.0 Media Caster

Media Caster is the high performance, multi-functional all-in-one system for ATSC 3.0 broadcasting. Media Caster integrates multiple encoders, multiplexer, signaling & caption server and scheduler into a single system.

Key Specifications

Standards Compliance

Fully compliant with ATSC 3.0 standards

Signal Input (SDI)

12G-SDI / HD-SDI

Signal Input (IP)

SMPTE 2110

Signal Output

ATSC3.0 MMT/ROUTE over IP, ATSC 3.0 STL-TP over IP

Synchronization

PTP, NTP

Management

Web UI control / management / monitoring

Key Features

Fully compliant with ATSC 3.0 standards
Integrated encoder support
Scheduler support — ATSC 3.0 SFN adaptation, multiple Sub-Frame & PLP, LDM/TDM/FDM mode, STL-TP ECC (SMPTE 2022-1) for forward error correction, STL-TP with L1/L2 (LMT) signal generation, configuration of ATSC 3.0 modulator, validation check of ATSC 3.0 configuration parameters
Multiplexing & Signaling (LLS & SLS), and Captioning
Control / management / monitoring via Web UI
Synchronization: PTP, NTP
Input: SDI (12G-SDI/HD-SDI), IP (SMPTE 2110)
Output: ATSC3.0 MMT/ROUTE over IP, ATSC 3.0 STL-TP over IP
